Size and Weight
|
Surface Pro 9:
- Length: 287 mm (11.3 inch)
- Width: 209 mm (8.2 inch)
- Height: 9.3 mm (0.37 inch)
- Weight: 879 g (1.94 lb)
Surface Pro 9 with 5G:
- Length: 287 mm (11.3 inch)
- Width: 209 mm (8.2 inch)
- Height: 9.3 mm (0.37 inch)
- Weight: 883 g (1.95 lb) (mmWave) or 878 g (1.94 lb) (Sub6)
|
Memory and Storage
|
Surface Pro 9:
- Memory: 8GB, 16GB, 32GB (LPDDR5 RAM)
- Storage: Removable drive (SSD) options: 128GB, 256GB, 512GB, 1TB
Surface Pro 9 with 5G:
- Memory: 8GB or 16GB (LPDDR4x RAM)
- Storage: Removabledrive (SSD) options: 128GB, 256GB, 512GB
|
Display
|
Surface Pro 9:
- Screen: 13-inch PixelSense™ Flow Display
- Resolution: 2880 X 1920 (267 PPI)
- Colour profile: sRGB and Vivid Refresh rate up to 120Hz (Dynamic refresh rate supported)
- Aspect ratio: 3:2
- Contrast ratio 1200:1
- Adaptive Colour
- Auto Colour Management supported
- Touch: 10-point multi-touch
- Dolby Vision IQ™ support
- Gorilla® Glass 5
- Brightness: 450 nits maximum (typical), 2 nits minimum
Surface Pro 9 with 5G:
- Screen: 13-inch PixelSense™ Flow Display
- Resolution: 2880 X 1920 (267 PPI)
- Colour profile: sRGB and Vivid
- Dynamic refresh rate up to 120Hz
- Aspect ratio: 3:2
- Contrast: 1200:1
- Adaptive Colour
- Touch: 10-point multi-touch
- Gorilla® Glass 5
- Brightness: 450 nits maximum (typical), 5 nits minimum
|
Battery life
|
Surface Pro 9: Up to 15.5 hours of typical device usage
Surface Pro 9 with 5G: Up to 19 hours of typical device usage
|
Processor
|
Surface Pro 9: - 12th Gen Intel® Core™ i5-1245U processor
- 12th Gen Intel® Core™ i7-1265U processor
- Options with storage 256GB and above built on the Intel® Evo™ platform
Surface Pro 9 with 5G: - Microsoft SQ® 3 processor
- Neural Processing Unit (NPU)
|
Graphics
|
Surface Pro 9: Intel® Iris® Xe graphics
Surface Pro 9 with 5G: Microsoft SQ® 3 Adreno™ 8CX Gen 3
|
Security
|
Surface Pro 9:
- TPM 2.0 chip for enterprise-grade security and BitLocker support
- Enterprise-grade protection with Windows Hello face sign-in
- Windows 11 Secured-core PC
Surface Pro 9 with 5G:
- Enhanced security with Microsoft Pluton
- Enterprise-grade protection with Windows Hello face sign-in
- Windows 11 Secured-core PC
|
Ports
|
Surface Pro 9:
- 2 x USB-C® with USB 4.0/Thunderbolt™ 4
- 1 × Surface Connect port
- 1 x Surface Keyboard port
Surface Pro 9 with 5G:
- 1 × nano SIM
- 2 x USB-C® 3.2
- 1 × Surface Connect port
- 1 x Surface Keyboard port
|
Software
|
Surface Pro 9:
- Windows 11 Pro or Windows 10 Pro
- Preloaded Microsoft 365 Apps
- Microsoft 365 Business Standard, Microsoft 365 Business Premium, or Microsoft 365 Apps 30-day trial
Surface Pro 9 with 5G:
- Windows 11 Pro on ARM
- Preloaded Microsoft 365 Apps
- Microsoft 365 Business Standard, Microsoft 365 Business Premium or Microsoft 365 Apps 30-day trial
|
Cameras
|
Surface Pro 9: - Windows Hello face authentication camera (front-facing)
- Front-facing camera with 1080p full HD video
- 10.0MP rear-facing autofocus camera with 1080p HD and 4k video
Surface Pro 9 with 5G: - Windows Hello face authentication camera (front-facing)
- Front-facing camera with 1080p full HD video
- 10.0MP rear-facing autofocus camera with 1080p HD and 4k video
|
Pen & accessories compatibility
|
Pen compatibility:
Surface Pro 9:
- Designed for Surface Slim Pen 2
- Integrated storage and wireless charging for Surface Slim Pen 2
- Supports tactile signals
- Supports Microsoft Pen Protocol (MPP)
Surface Pro 9 with 5G:
- Designed for Surface Slim Pen 2
- Integrated storage and wireless charging for Surface Slim Pen 2 with Surface Pro Signature Keyboard
- Supports tactile signals
- Supports Microsoft Pen Protocol (MPP)
Keyboard compatibility:
- Surface Pro Signature Keyboard
- Surface Pro Keyboard
- Surface Pro X Signature Keyboard
- Surface Pro X Keyboard
|
Audio
|
Surface Pro 9:
- Dual far-field Studio Mics
- 2W stereo speakers with Dolby Atmos
Surface Pro 9 with 5G:
- Dual far-field Studio Mics
- 2W stereo speakers
|
Battery Capacities
|
Surface Pro 9: - Battery Capacity Nominal (WH) 47.7 Wh
- Battery Capacity Min (WH) 46.5 Wh
Surface Pro 9 with 5G: - Battery Capacity Nominal (WH) 47.7 Wh
- Battery Capacity Min (WH) 46.5 Wh
|
Accessibility
|
- Compatible with Surface Adaptive Kit
- Compatible with Microsoft adaptive accessories
|
Sensors
|
- Accelerometer
- Gyroscope
- Magnetometer
- Ambient Colour Sensor (Brightness and Colour)
|
Network and connectivity
|
Surface Pro 9:
- Wi-Fi 6E: 802.11ax compatible
- Bluetooth® Wireless 5.1 technology
Surface Pro 9 with 5G:
- Wi-Fi 6E: 802.11ax compatible
- Bluetooth® Wireless 5.1 technology
- Location: GPS, Glonass, Galileo and Beidou Support
- NanoSIM and eSIM support
- Supports 5G
|
What’s in the box
|
Surface Pro 9:
- Surface Pro 9
- Power Supply
- Quick Start Guide
- Safety and warranty documents
Surface Pro 9 with 5G:
- Surface Pro 9 with 5G
- Power Supply
- Quick Start Guide
- Safety and warranty documents
- SIM Card access tool
|
Exterior
|
Surface Pro 9:
- Casing: Aluminium
- Colours: Platinum, Graphite
- Physical buttons: Volume, Power
Surface Pro 9 with 5G:
- Casing: Aluminium
- Colours: Platinum
- Physical buttons: Volume, Power
|
Warranty
|
1-year limited hardware warranty
|
Serviceability
|
Replaceable components include:
- Display
-
Battery
- Surface Connect Port
-
Thermal Module (Surface Pro 9 with 5G only)
- Thermal Module with Fan (Surface Pro 9 only)
- Cameras
- Speakers
- Buttons
-
Camera Deck (Surface Pro 9 with 5G only)
-
Wi-Fi Deck (Surface Pro 9 only)
- Back Cover
- Removable SSD
- Removable SSD Door
- Kickstand
- Motherboard (Surface Pro 9 with 5G only)
|
Sustainability
|
Surface Pro 9:
- Meet ENERGY STAR® requirements
- Registered EPEAT® Gold in the US and Canada Sustainable Products & Solutions | Microsoft CSR
Surface Pro 9 with 5G:
- Meet ENERGY STAR® requirements
- Registered EPEAT® Gold in the US and Canada Sustainable Products & Solutions | Microsoft CSR
|
